Switching/0-10 V Fixture Controller

Lutron

SKU:
LQSE-4S10-D
Switching/0-10 V Fixture Controller

Description

The Power Module family is a group of modular products for the control of lighting loads. • Model Number: LQSE-4S10-D - Power Module unit for Switching only Features • Includes QS link for seamless connection to a HomeWorksR QS system. • Power Module units can be used in a HomeWorksR QS system to control and manage light in an entire home or building.

Extra Information

Brand:
Lutron


Specifications

Power • 230 V 50/60 Hz • Lightning strike protection meets ANSI/IEEE standard 62.31-1980. Can withstand voltage surges of up to 6 000 V and current surges of up to 3 000 A. • Current draw: 50 mA max • Standby power : 1 W • BTUs/hour when fully loaded: 4 Output Zone Ratings • Each zone is rated at 10 AX for switching. Rated for restrictive, capacitive, or inductive lighting loads as defined by IEC/EN 60669-2-1. • Switched outputs utilize latching relays to maintain relay state if control power is lost. • 0-10 V rated for 50 mA maximum output, source or sink per zone. Standards • IEC/EN 60669-2-1, EN50428 • Lutron Quality Systems registered to ISO 9001:2008 • CE • C-Tick S Environment • Ambient Temperature Operating Range (inside mounting panel): 0 ºC to 40 ºC • Calibration point maximum: 65 ºC • Relative humidity: less than 90% non-condensing • For indoor use only Terminals • Mains wiring: 0,5 mm2 to 6,0 mm2 • 0-10 V Wiring: 0,5 mm2 to 2,5 mm2 • CCI Wiring: 0,5 mm2 to 6,0 mm2 • Zone wiring: 0,5 mm2 to 6,0 mm2
