SURFACE MOUNT DOOR STATION SILVER

Savant

SKU:
DOR-SM0S-00
SURFACE MOUNT DOOR STATION SILVER

Description

The Savant Door Station is a luxury IP door intercom that provides reliable access control, communication and video surveillance. This kit includes everything necessary for a surface mount installation including the backbox and silver frame. Key Features: - Microphone and speaker built in - Wide-angle HD camera with infrared light and night vision - Tamper switch available for detecting unauthorized device intrusions - Powered directly from the LAN equipped with PoE 802.3af supporting network elements - Includes available blank spot to add one additional module: - 9155031 - Door Station Keypad Module - 9155038 - Door Station Display - 9155042 - Door Station RFID Card Reader 13.56MHZ Nfc Ready - 9155046 - Door Station Bluetooth Module

Extra Information

Brand:
Savant


Specifications

Power: POE: PoE 802.3af (Class 0 - 12.95W) Power Supply: 12V ± 15%/ 2A DC Connections: Ethernet: 10/100BASE-TX with Auto-MDIX Relay: NC/NO contacts, max 30 V/1 A AC/DC GPIO: 8 to 12 V DC depending on Power supply (PoE: 10 V; adapter: source voltage minus 2 V), max 400mA Environmental: Operating Temp: -40°C – 60°C Operating Humidity: 10%-95% Certification: IP54, IK08 Camera: Resolution JPEG: 1280x960 Resolution In Call: 640x480 Viewing Angle: 120° (H), 90° (V), 145° (D) Night Vision: Yes Dimensions: Width: 4.21 in (10.7 cm) Height: 9.21 in (23.4 cm) Protrusion: 1.1 in (2.8 cm) For Pre-Construction see 9155062
