Integrated Switching Power Supply

AVGear

SKU:
AVG-PSU12
Integrated Switching Power Supply

Description

The PSU12-UL is an integrated switching power supply designed for converting AC into DC power. It provide 2 input channels and 12 output channels, input voltage 100-240VAC, output 5/12/24VDC. Features-
  • Double input channel designed for ensuring a stable AC power source.
  • 12 Output channels, each channel has three kinds of output voltage (5/12/24V) can be selected.
  • Output channels can be switched on and off via the Front panel, RS232, GUI and TCP/IP.
  • Output voltage (5/12/24V) can be selected via the TACT switches on the rear panel, RS232 or the GUI.
  • Supports online firmware updates.

Extra Information

Brand:
AVGear


Specifications

Input + Output Input Port - AC1 & AC2 Input Voltage-  50~60Hz 100~240VAC 50~60Hz 100~240VAC Output Port - Total 12 DC ports (2 pin Phoenix connector) Output Voltage - 5V, 12V and 24V selectable Output Voltage Range - 5V: 4.75V – 5.25V 12V: 11.4V – 12.6V 24V: 22.8V – 25.2V Maximum output power consumption of signal channel - 5V:12W 12V:15W 24V:15W Maximum output power consumption for single supply - 110V:90W 240V:180W Maximum output power consumption for dual supply - 180W Control Front panel Front Panel: 1-12, total 12 buttons Rear Panel: Total 12 TACT switches, named SELECT. RS232 Control RS232 port (3 pin Phoenix connection) Supported Baud Rates: 1200, 2400, 4800, 9600(default), 19200, 38400, 57600, 115200 GUI Control- TCP/IP (RJ45) Default IP: 192.168.0.178 Port: 4001 General Temparature 0 -50 C Humidity 10%- 90% Dimensions (W*H*D) 437 x 44 x 357mm Net Weight 4.2Kg
