Name: COMPLETE 4x4 KIT with 4 HDBT Transmitters and Receivers 4K HD
Brand: AVGear
SKU: AVG-MHD4K-44 HD70 KIT
Price: 1622.73 AUD
Availability: InStock

Description

This product is a professional 4×4 HDMI 2.0 Matrix Switcher with built in Audio Matrix. It includes 4 HDMI inputs, 4 HDMI outputs and the last two outputs feature down-scaling, which is designed for switching two HDMI2.0 and HDCP2.2 compliant signals. It also features 4 SPDIF and 4 analog audio outputs for the audio matrix. Includes 4 x HD70 SETS and 4 x ZIGEN 2M HDMI Cables Features

4×4 HDMI 2.0 Matrix Switcher.
Supports 4K/60 4:4:4, supports HDR, HDCP2.2 compliant.
Audio Matrix, audio out can de-embedded from any input or output.
Individual volume adjustment on each L+R output.
Supports 4K to 1080p down-scaling on 2 outputs.
HDMI out provides 2.5W to power an Active Optical Cable (AoC).
HDMI Output supports up to 5V500mA for an AoC cable
Controllable by front panel, IR, RS232 and TCP/IP.

Extra Information

Brand:

AVGear

Specifications

Video
Video Input	(4) HDMI
Video Input Connector	(4) Type-A female HDMI
Video input Video Resolution	Up to 4K@60Hz 4:4:4
Video Output	(4) HDMI
Video Output Connector	(4) Type-A female HDMI,
Video output Video Resolution	Up to 4K@60Hz 4:4:4
HDMI Output	Supports up to 5V500mA for AoC cable
HDMI Version	Up to 2.0
HDCP Version	Up to 2.3
HDMI Audio Signal	LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital® Plus, DTS:X™, and DTS-HD® Master Audio™ pass-through.
Digital Audio Output
Output	(4) Digital SPDIF audio
Output Connector	(4) Toslink connector
Digital SPDIF Audio Format	Supports PCM, Dolby Digital, DTS, DTS-HD
Frequency Response	20 Hz to 20 kHz, ±1dB
Max Output level	±0.05dBFS
THD+N	< 0.05%, 20 Hz – 20 kHz bandwidth, 1 kHz sine at 0 dBFS level (or max level)
SNR	> 90dB, 20Hz-20 kHz bandwidth
Crosstalk Isolation	< -70 dB, 10 kHz sine at 0dBFS level (or max level before clipping)
Noise	-90dB
Analog Audio Output
Output	(4) Analog L/R Audio
Output Connector	(4) L&R (RCA)
Digital SPDIF Audio Format	PCM 2CH
Frequency Response	20 Hz to 20 kHz, ±1dB
Max output level	2.0 Vrms ± 0.5 dB. 2 V = 16 dB headroom above -10 dBV (316 mV) nominal consumer line level signal
THD+N	< 0.05%, 20 Hz – 20 kHz bandwidth, 1 kHz sine at 0 dBFS level (or max level)
SNR	> 80dB, 20Hz-20 kHz bandwidth
Crosstalk Isolation	< -80 dB, 10 kHz sine at 0 dBFS level (or max level before clipping)
L-R Level deviation	< 0.05 dB, 1 kHz sine at 0 dBFS level (or max level before clipping)
Frequency Response Deviation	< ± 0.5dB 20Hz – 20KHz
Output Load Capability	1k ohm and higher (supports 10x paralleled 10k ohm loads)
Noise	-80dB
Control
Control Port	(1) IR IN, (1) RS232, (1) FIRMWARE, (1) TCP/IP
Control Connector	(1) 3.5mm jack, (1) 3-pin terminal block, (1) USB-A,(1) RJ45,
General
Transmission Distance	4K/60Hz/444 5m,4K/60Hz/420 10m,1080P 15m
Bandwidth	18Gbps
Operation Temperature	-5~ +55℃
Storage Temperature	-25 ~ +70℃
Relative Humility	10%-90%
External Power Supply	Input: AC 100~240V, 50/60Hz; Output: 24V DC 1.25A
Maximum Power Consumption	18.3W
Dimension (WHD)	436.4mm44mm236mm
Net Weight	2.6kg

Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart.

	Input			Output
#	Resolution	Refresh	Color Space	Downscale	1080p Specs
1	3840×2160	60	4:4:4	Support	1080p@60Hz 4:4:4
2	3840×2160	30	4:4:4	Support	1080p@30Hz 4:4:4
3	3840×2160	24	4:4:4	Support	1080p@24Hz 4:4:4
4	3840×2160	60	4:2:0	Support	1080p@60Hz 4:4:4
5	3840×2160	30	4:2:0	Support	1080p@30Hz 4:4:4
6	3840×2160	24	4:2:0	Support	1080p@24Hz 4:4:4
7	3840×2160	60	4:2:2	No Support	N/A
8	3840×2160	30	4:2:2	No Support	N/A
9	3840×2160	24	4:2:2	No Support	N/A
